Key Features
– POE++ compatible
– Gigabit Ethernet
– Shielded enclosure and connectors
-5 KA discharge capability
| Network | Gigabit Ethernet (Cat.5E) | |
| Nominal line voltage | Un | 48 Vdc |
| Max. DC operating voltage | Uc | 60 Vdc |
| Max. frequency | f max. | 125 MHz |
| Max. data rate | 10/100/1000 Mbps | |
| Insertion loss | < 1 dB | |
| Max. load current | IL | 5000 mA |
| Minimum insulation Resistance | 1 GΩ (at 50V) | |
| Nominal impulse discharge current @ 8/20µs Test ±5 time | In L/L | 5KA |
| Maximum impulse discharge current @ 8/20µs Test 1 time | In L/PE | 10KA |
| Technology | GDT + Clamping diode | |
| SPD configuration | 8 wires + shielded | |
| Connection to Network | RJ45 shielded connectors Female input/output | |
| Format | Plastic box with connectors input/output | |
| Mounting | Mounting, Screw, Nut + Cable shoe | |
| Housing material | ABS | |
| Operating temperature | Tu | -40/+85°C |
| Protection rating | IP66 | |
| Failsafe mode | Short-circuit â Transmission cut off | |
| Disconnection indicator | Transmission interrupt - default mode 2 | |
| Pinout | (1-2)(3-6)(4-5)(7-8) | |
| Dimensions | See diagram | |
| Weight | 0.13 kg |
